L&L e18M-3 Easy-Fire Kiln

Save $406.00
Regular price $3,605.00 $3,199.00
Unit price
per
SKU : LKE18M3
Fires to
Cone 10
Power
240 or 208 V
Size
Small studio
Loading
Top-loading
Made for
Pottery
What you get
Kiln only
Free Shipping Eligible on Orders Over $89
Availability

Shipping calculated at checkout.
  • Free ShippingLower 48 · orders $89+
  • Free InsuranceEvery order covered to your door
  • Kiln Experts on StaffCall 888-774-2529
  • Since 194680 years serving potters

See full specifications



L&L KIlnsL&L e18M-3 Easy-Fire Kiln

22" Tall, 3" Brick

New easy-to-load medium height!
16.5” across, 22.5” deep, 3.2 cubic feet.
Requires 50 amp breaker on 240/1 residential power. Other voltages combinations available.
3 Zones

L&L e18M-3 Features
☎︎Call us to speak to one of our kiln expertsLet us help guide you to the right kiln for your needs!(888) 774-2529We are available 8:30 – 5:00 ESTLeave a message after hours with name, number, and the best time for us to call you back.Sheffield Pottery · Since 1946Temperature Rating: Cone 10, 2350°F, 1290°C
Loading: Lid position, when open, rests at an angle away from the kiln in Stainless Hinge.
Stand: Heavy-duty 14 gauge full solid stand with multiple bends for strength. Bolt on legs. Feet protectors included.
Assembly: Three sections stack on top of each other. Easy to assemble. Bottom is reversible.
Construction: Stainless steel wrapped around brick with 3 clamps on each section. All stainless screws.
Insulation: 3” K23 firebrick.
Brick Coating: Reflective coating protects brick and reduces dusting.
Element Holders: Hard ceramic element holders protect brick.
Elements: Heavy-duty. 2 elements per 9” high section.
Element Connections: Proprietary all-ceramic element connection block
makes changing elements easy.
Control Panel: All controls and components are mounted in a separate control panel that is piggy-backed to the element connection box. A layer of insulation and this separation helps keep the controls cool. The
control panel and element box are hinged for easy access and maintenance. Control box can be easily removed for servicing. On/off switch and control use are included.
Genesis Touchscreen controller:  mounted in an easy-open cool-firing piggyback control panel that is angled for easy viewing of control.
Zone Control: Two zones with separate thermocouples.
Peephole Plugs: Non-fragile solid ceramic with heat-locked head. 1” diameter full-view non-tapered. One per section.
Thermocouples: Type K 8 gauge with ceramic protection tubes.
Relays: Mercury free relays.
Power Cord/Plug: 50 Amp NEMA 6-50 six foot cord included for one phase, 50 Amp NEMA 15-50 six foot cord included for three phase.
Instructions: Complete visual instructions with control reference, process information, assembly, troubleshooting, and parts list. In addition a web videos show how to assemble the kiln and how to fire it. (https://www. youtube.com/user/LLKilns#p/u)
Warranty: Limited 3 year warranty. (See hotkilns.com/warranty.pdf ).
UL Listing: c-MET-us listed to UL499 standards.

Easy Fire Kiln Options

Furniture Kit
DynaTrol Controller:
with 4 Easy-Fire programs, 6 Vary-Fire programs, Pre-Heat, Delay, Program & Segment Review, and Diagnostics.
Quad Elements
Rolling Stand Leg Kit

Thermocouple Options: Type S Platinum or 1/4” Pyrocil Metal Sheathed
Vent System: Vent-Sure downdraft vent

Kiln Buyers Guide Not sure which kiln fits your work? Sizing, voltage, controllers and more, explained. Read the guide →
Specifications
Model Number Part Number for 3” Brick Volts/Phase Watts Amps Wire Size Fuse Size Power Connection
e18M-3-240 (USA) K-E-18M3/31 240/1P 8000 33.3 8 ga 50 Amp 6-50 Cordset
e18M-3-240-3P (USA) K-E-18M3/32 240/3P 8000 23.1 10 ga 30 Amp 15-50 Cordset
e18M-3-208 (USA) K-E-18M3/21 208/1P 8000 38.5 8 ga 50 Amp 6-50 Cordset
e18M-3-208-3P (USA) K-E-18M3/22 208/3P 8000 26.6 10 ga 40 Amp 15-50 Cordset
e18M-3-220 (World) K-E-18M3/41 220/1P 8000 36.4 8 ga 50 Amp Direct Wire
e18M-3-380-3PY (World) K-E-18M3/52 380/3PY 8000 14.5 14 ga 20 Amp Direct Wire

L&L Easy-Fire Kiln Comparison

Easy-Fire is L&L's main line of top-loading pottery kilns. Every current model has 3" K23 firebrick, a Genesis touchscreen with zone control (two zones in S and M models, three in T models), hard ceramic element holders, and a 6-foot cord with plug. They come in four diameters and three heights.

Model Inside (diameter × height) Capacity Max temp Amps Plug Best for
e14S-3 13.5" × 18" 1.5 cu ft Cone 10 (2350°F) 16 NEMA 6-20 Small pieces and test firings on a 20-amp circuit
e18S-3 16.5" × 18" 2.5 cu ft Cone 10 (2350°F) 23.9 NEMA 6-50 Hobby potters and small home studios
e18M-3 16.5" × 22.5" 3.2 cu ft Cone 10 (2350°F) 33.3 NEMA 6-50 Home studios that want a little more height
e18T-3 16.5" × 27" 3.7 cu ft Cone 10 (2350°F) 35 NEMA 6-50 Tall work in a small footprint
e23S-3 22.3" × 18" 4.4 cu ft Cone 10 (2350°F) 39.4 NEMA 6-50 Wide bowls and platters, with an easy reach to the floor
e23M-3 22.3" × 22.5" 5.5 cu ft Cone 10 (2350°F) 48 NEMA 6-50 Active home studios that want an easier reach than a tall kiln
e23T-3Best seller 22.3" × 27" 6.7 cu ft Cone 10 (2350°F) 48 NEMA 6-50 Serious home studios and schools
e28S-3 28" × 18" 6.8 cu ft Cone 10 (2350°F) 47.9 NEMA 6-50 Large platters and wide sculpture
e28M-3 28" × 22.5" 8.5 cu ft Cone 10 (2350°F) 48 NEMA 6-50 Big, wide loads for schools and studios
e28T-3 28" × 27" 10.2 cu ft Cone 8 (2280°F) 48 NEMA 6-50 The biggest Easy-Fire: large low-fire loads, or cone 10 on three-phase power

Ratings are for 240V single-phase power. On 208V single-phase, the e28M-3 is rated cone 8 and the e28T-3 cone 5. Every model except the e14S-3 also comes in a three-phase version, rated cone 10 with a NEMA 15-50 plug. Amps change with voltage, so check the spec table on each product page or tell us your voltage when you call. For frequent cone 6 firing or higher in a 28" kiln, L&L recommends the eQ2827-3 over the e28T-3.

Most Easy-Fire models also come as Easy-Fire kiln packages, with a Vent-Sure downdraft vent and a furniture kit of shelves and posts.
